Price:
3,250.00 ৳
DAHUA PFS3005-4ET-60 5 PORT UNMANAGED SWITCH
Key Features
Type - Network Switch
Number of Total Port - 5 Port
PoE - Yes
Manageability - Unmanaged
Network Standards - IEEE802.3, IEEE802.3u, IEEE802.3x
Data Transfer Rate - 10/100 Mbps
Form Factor - Desktop/Wall Mounting
Body Color - Black
Specification | |
|---|---|
| Model | DH-PFS3005-4ET-60 |
| Ethernet Port | Port 1-4: 4 × RJ-45 10/100M (PoE), Port 5: 1 × RJ-45 10/100M (uplink) |
| PoE Power Consumption | Port 1: ≤ 60 W (Hi-PoE), Ports 2-4: ≤ 30 W, Total: ≤ 60 W |
| Power Consumption | Idling: 0.8 W, Full load: 60 W |
| Standard | IEEE802.3, IEEE802.3u, IEEE802.3x |
| PoE Protocol | IEEE802.3af/ IEEE802.3at/ Hi-PoE |
| Power Supply Pin | 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-) |
| Long Distance | 250 m long distance PoE transmission |
| PoE Power Management | Yes |
| PoE Watchdog | Yes |
| Switching Capacity | 1.8 Gbps |
| Packet Forwarding Rate | 744 Kbps |
| Packet Buffer Memory | 1 Mbit |
| Flow Control | Enabled by default |
| Working Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Application Humidity | 5%–95% (RH) |
| Power Input | 48 V – 57 V DC |
| Lightning Protection | Common mode: 4 kV, Differential mode: 2 kV |
| ESD Protection | Air discharge: 8 kV, Contact discharge: 6 kV |
| Wall-mount Installation | Yes |
| Anti-theft Lock Hole | Yes |
| Weight | 0.30 kg (0.64 lb) |
| Dimensions | 130 mm × 85 mm × 26 mm (5.12″ × 3.35″ × 1.02″) |
| Brands | Dahua |
